The credenza that chills the water: Altagamma by Estel puts a fridge inside the 70⅞ in and 94½ in units
Let's discuss your project
Trade terms for professionals and design studios
Estel builds a refrigerator into two pieces of the Altagamma storage range: the 70⅞ in cabinet, code GA903, and the 94½ in composition GA955, two 23⅝ in modules around a 47¼ in one with a glazed center top. Both stand 34¼ in high and 18⅛ in deep, finished in veneer, in Pelle Soft or in Ecopelle Time. On the price list they are the only units of the family marked fridge-ready, so the choice of credenza and the choice of fridge are made on the same line.
Under the desk, a frame. Its aluminum legs have a 4⅜ in profile and ⅝ in of thickness, finished in anodized steel-tone aluminum, matte bronze or pewter quartz; a modesty panel 4⅜ in thick links them and holds the electrification bay that feeds the top access. Among designer office desks this is one, the design credit goes to Estel R&D, the manufacturer’s own department, and to no outside name.
Count the people first; the range is drawn around that number. For one person, the fixed desk at 29½ in, from 70⅞ × 35⅜ to 94½ × 39⅜ in, or the version with a service cabinet on an 82⅝ × 66⅞ in footprint; among sit-stand desks, Altagamma Life lifts its top to 49¼ in. For two, the meeting desk of 94½ or 110¼ in, leather at the center and glass on both wings. For a board, the executive suite runs into conference tables up to 236¼ in, octagon included.
La Mercanti USA asks where the outlet is behind the credenza before it fixes the fridge position on the plan.
Technical information based on data declared by the manufacturer.
Collection: Altagamma, Executive & Meeting chapter of the Executive & Common Area catalog: executive desks, meeting desks, conference tables and storage
Manufacturer: Estel Group, Thiene, Vicenza, Italy
Design: Estel R&D
What it is: executive desk on an aluminum frame base with a modesty panel fitted for cable management; fixed version at 29½ in and Sit&Stand version from 29½ to 49¼ in
Base: aluminum legs with a 4⅜ in profile and ⅝ in thickness; finishes anodized steel-tone aluminum, matte bronze, pewter quartz
Modesty panel: 4⅜ in thick, finished to match the top; houses the electrification bay; in veneer on the versions with service cabinet, Life and glass
Tops: 1⅛ in MDF panel faced in veneer, Ecopelle Time or Pelle Soft; ⅝ in clear glass; Life tops 2 in
Veneers: Eucalipto Naturale, Eucalipto Scuro, Noce Canaletto, Rovere Dark, Rovere Naturale (Estel sample book)
Pelle Soft: 24 named colors, from Bianco to Nero
Ecopelle Time: 24 coded variants
Fixed desk: 70⅞ × 35⅜, 82⅝ × 39⅜, 94½ × 39⅜ in, 29½ in high; GAA54, GAA51, GAA52; in glass 70⅞ × 35⅜ and 82⅝ × 39⅜ in, GAZ94 and GAZ91
Desk with service cabinet: 82⅝ × 66⅞ × 29½ in, GAZ00 and GAZ04, right or left; top 82⅝ × 35⅜ in, cabinet 74¾ × 19⅝ in, 22½ in high; modesty panel, side panels and cabinet in veneer
Sit&Stand with service cabinet: same footprint and cabinet as the fixed version above, top rising to 49¼ in, GAZ10 and GAZ14, right or left
Life version: 82⅝ or 94½ × 39⅜ in, same travel as the Sit&Stand, GAA70 to GAA92, right or left, top access always included; with a fixed return 47¼ × 23⅝ in: 82⅝ or 94½ × 86⅝ in, GAA75 to GAA78; rising return as an option declared in the catalog
Meeting desk: 94½ and 110¼ × 47¼ × 29½ in with a center top in veneer, eco-leather or leather and glass side tops, GAZ20 and GAZ22; all glass GAZ80 and GAZ82; Pelle Soft with veneer sides 94½, 110¼ and 118⅛ in, GAZ26 to GAZ30
Conference tables: round Ø 51⅛ and 59 in; square 63 × 63 in; rectangular 126 and 141¾ × 47¼ in, 165⅜, 189 and 236¼ × 55⅛ in; octagonal 236¼ × 47¼/55⅛ in; 29½ in high; glass, veneer, eco-leather, leather and combinations
Electrification: two-sided or frame top access, in leather or wood; the glass top cannot be wired with top access; cable grommet standard on tables in veneer, eco-leather and leather; outlet modules Type 1 GC030 (3 Schuko + 2 RJ45 cat. 6), Type 2 GC032 (3 Schuko + 2 RJ45 + 2 USB 5 V), Type 3 GC034 (3 Schuko + 2 RJ45 + HDMI + USB), Type 4 GC036 (3 Schuko + 2 USB 5 V), black, 15 × 2⅜ × 1⅝ in or 17¾ × 2⅜ × 1¾ in, with a 220 V connector with interlock; Type 2 and 3 not for the service cabinet; cable GC090 H05 VV-F, 9 ft 2 in, Schuko plug and GST 18-3 socket; international standards on request
Storage units: family worked at 45°: pedestals 26 × 18½ × 22⅞ in with three drawers or with a drawer and a deep file drawer on a fifth castor, recessed handle with brushed steel back; service cabinets 29⅛, 40⅛ and 48 in long, 26¾ × 26 in, on feet or castors; cabinets 34¼ in high, 39⅜, 59, 70⅞ and 78¾ in long, and compositions of 86⅝, 94½ and 126 in with a glazed center top; refrigerator fittable in the 70⅞ in and 94½ in units
Veneer care: dry cloth; neutral detergent with a barely damp cloth; never microfiber, acids or alkalis; silicone-free furniture polish at most once a year
Leather and eco-leather care: Pelle Soft never with water or detergents, soft dry cloth, brush or low-power vacuum; Ecopelle Time with liquid soap and warm water, cold rinse; sanitizer recommended by Estel Care
Glass and aluminum care: glass with a damp cloth or glass cleaner, alcohol-based sanitizers, limited load; anodized aluminum with neutral detergent, never acids or lemon juice, 70% alcohol to sanitize
Recommended room conditions: 64-73 °F, relative humidity 45-60%, at least ⅜ in from the wall
Files available: technical data from the price list, Executive & Common Area catalog, Product Care
In the catalog settings: Embrasse Office seating, Dolly sofa and armchairs, Libra bookcase, Deck storage, E-Wall hanging units
La Mercanti USA Llc — your partner for Italian design and contract supply.
Los Angeles, CA, USA · +1 855 335 8079 · info@lamercanti.us
Supply, quotes, specifications and project support across the United States and North America.
Documents and Catalogs
Let us know which finishes you'd like to explore
Altagamma
Designer Desks
FAQ
After a season of colds, what sanitizes an Altagamma without hurting its surfaces?
Estel’s Product Care sets the sequence: clean first, then sanitize with 0.1% bleach or 0.5% hydrogen peroxide. Where bleach would harm the surface, as on veneer, the maker points to disinfectants with 70% alcohol or to quaternary ammonium compounds. Anodized aluminum takes 70% alcohol on a soft cloth, rinsed with a damp one; glass tolerates alcohol-based household sanitizers followed by a rinse. Pelle Soft and Ecopelle Time are the exception: Estel asks for its own sanitizing detergent through Estel Care, on a soft sponge, after a test in a hidden spot. Then air the room.
Why does the Altagamma file pedestal roll on five castors instead of four?
Because of what the second model holds. The price list offers two pedestals of identical size, 26 × 18½ × 22⅞ in: GA380 with three drawers, and GA381 with one drawer above a deep file drawer for folders and oddments, which Estel equips with a fifth castor. Both roll on castors and both open with a recessed handle lined in brushed steel, and the finish is taken from the desk: Pelle Soft, Ecopelle Time or veneer. The two models share every measurement, so the order line carries one code or the other, GA380 or GA381, and the fifth castor comes with the code.
Leather or wood: what are the two faces of the Altagamma top access?
The lid in the top can be upholstered in leather or made of wood, and the price list offers it in two builds: bifacciale or with a frame, as Estel names them in its tables. Under the lid runs the cable bay of the modesty panel, which the price list says can hold a large quantity of cables, reached by the user from the top. One limit is printed with an asterisk: the clear glass top cannot be wired with a top access, so the lid belongs to the veneer, Ecopelle Time and Pelle Soft tops only. On the Life version the top access is always included in the code.
How is the Altagamma meeting desk divided between leather and glass?
Into three tops on one frame. On the 94½ in version, codes GAZ20 and GAZ22 cover a center of 31½ in in veneer, Ecopelle Time or Pelle Soft between two glass tops of 31½ in each; on the 110¼ in version the center grows to 47¼ in and the glass wings stay at 31½ in. The modesty panel matches the center top. The side tops are always clear glass, whatever the center. Two more families exist, all-glass with codes GAZ80 and GAZ82, and Pelle Soft with veneer sides in 94½, 110¼ and 118⅛ in, GAZ26 to GAZ30.
What does the Life version of Altagamma add when it comes with a return?
A fixed return top of 47¼ × 23⅝ in set above a veneer cabinet with drawers and an open bay, which takes the whole composition to 86⅝ in deep, codes GAA75 to GAA78. The main top keeps the Sit&Stand travel from 29½ to 49¼ in, while the modesty panel, the side panels and the cabinet stay in veneer. In its 2019 catalog Estel also shows the return as an option that rises through the same range, with a push-button pad and a display of the travel; the price list files the return as fixed, so the option is the catalog’s word, not a code.
Building the technical file for an Altagamma order: five documents to collect
Every number in an Altagamma specification lives in one of five documents that Estel publishes. Where to find codes, drawings, outlet modules, care rules and finish samples before the order goes out.
Pull the Executive & Meeting pages
Open the Estel price list Executive & Common Area, edition EU-09/21, at pages 16 to 36: that is the Altagamma chapter, with the overview of versions, the code tables for every desk and table, the dimensioned drawings in inches and the outlet modules. The list itself states that where it disagrees with a catalog on sizes or technical features, the price list prevails.
Add the storage chapter
The cabinets and pedestals of the collection are not in the desk pages but in the Storage & Cupboard chapter, pages 118 to 124 of the same list. There you find the finish table, the two pedestals, the service cabinets in three lengths, the 34¼ in cabinets and the three compositions, with the lengths in inches and the codes that go on the order.
Keep the catalog for the rooms
Estel’s 2019 catalog for the same range gives the collection pages 12 to 21: the presentation text of the price list, plus the photographed rooms with their captions, which name the finishes actually shown, the companion pieces and the versions. The captions are also where Estel describes the return of the Life as able to rise from 29½ to 49¼ in, an option the price list does not code.
File the Product Care sections
Estel’s Product Care 2020 covers the materials of the collection in separate sections: Veneer, Leather, Eco-leather, Glass, Aluminum and Metals. Pull those pages together with the general chapter on room conditions and the sanitization page. Each section says, in the manufacturer’s words, what to use on that material and what to keep away from it.
Save the samples and the images
La Mercanti sends the Altagamma sample files from Estel: five veneers with their names, 24 Pelle Soft colors, 24 Ecopelle Time codes, clear glass and the three base finishes. Save them together with the eight product images La Mercanti supplies, and the file holds every finish the collection offers next to the codes that order it.
